Varitile MistralThe stately aesthetics of European styling

Mistral combines the benefits of steel roofing with classic European styling.

Enhance your roofline with Varitile’s strong, lightweight, virtually maintenance free Mistral tile.




Specifications

Minimum pitch 2/12  [10°]
Maximum pitch Vertical  [90°]
Size - overall* 51.38"x16.34"  [1305x415mm]
Size - cover* 48.82"x14.57"  [1240x370mm]
Gauge of steel** 26 gauge ZA [0,45mm]
Tiles per square* 20.25 pc [2,18 tiles/m²]
Weight per square* 134 pounds   [6,4kg/m²]
Weight per tile* 6.61 pounds [3,0kg]



    * The measurements  may vary slightly by the finish that is added to the panel.
    ** Steel thickness according to the EN 10346.


Standard stone chip colors

additional color options

Install guides

Please click here to download the install guide
